Conveyor / Heavy-duty Mobile Robott
หุ่นยนต์ลำเลียงสินค้าขนาดใหญ่ แบบสายพาน
คุณสมบัติการยกที่หลากหลายของหุ่นยนต์ AGV รุ่น CMR สำหรับงานรางขนถ่าย ลำเลียงสินค้าแบบสายพานลำเลียงสินค้าขนาดใหญ่ เพิ่มประสิทธิภาพในการทำงานในพื้นที่จำกัด ลดต้นทุน และพัฒนาการบริหารจัดการ
Conveyor Mobile Robot (CMR)
It supports docking with machine,
transmission line or tooling mechanism to fulfill the automated production needs. It has been optimized the obstacle avoidance, positioning accuracy and material testing.
Drived by roller, belt and chains, it supports docking with AMRs for material transferring
Docks with
the machine
Adaptable to various carriers, such as carton, tray, and pallet, etc.
FEATURE
C3-200LB2
200
Rated Load (kg)
1.2
Rated Speed (m/s)
SLAM
Navigation
0.5
Rated Acceleration (m/s²)
1415
Rotation Diameter (mm)
360° Laser+Auxiliary protection
Obstacle Avoidance
| Dimension L*W*H (mm) | : 1250*745*935 |
| Transferred Method | : Rollers |
| Weight (kg) | : 350 |
| Angular Accuracy (°) | : ±1 |
| Positioning Accuracy (mm) | : ±10 |
| Endurance (h) | : 8 |
C3-400B4
4*100
Rated Load (kg)
1.2
Rated Speed (m/s)
SLAM/QR code
Navigation
0.5
Rated Acceleration (m/s²)
1415
Rotation Diameter (mm)
360° Laser+Auxiliary protection
Obstacle Avoidance
| Dimension L*W*H (mm) | : 1250*745*1175 |
| Transferred Method | : Rollers |
| Weight (kg) | : 410 |
| Angular Accuracy (°) | : ±1 |
| Positioning Accuracy (mm) | : ±10 |
| Endurance (h) | : 8 |
Heavy-duty Mobile Robot (HMR)
Support large material transferring,
mainly used in e-commerce, electronics manufacturing, tobacco, automobile, machinery manufacturing and other large/medium-scale materials transferring.
Supports forward, backward, sidesway, skew, curve, rotation
Adopts 360° protection settings including laser, bumper, and scram button, etc.
Large tonnage electric lifting, adapts to high cleanliness environment
H8C-2000H
200
Rated Load (kg)
1.2
Rated Speed (m/s)
SLAM/QR code
Navigation
0.5
Rated Acceleration (m/s²)
Omni-directional
Driving Mode
360° Laser+Auxiliary protection
Obstacle Avoidance
| Dimension L*W*H (mm) | : 1900*1200*370 |
| Transferred Method | : Lifting |
| Weight (kg) | : 800 |
| Angular Accuracy (°) | : ±1 |
| Positioning Accuracy (mm) | : ±10 |
| Endurance (h) | : 8 |
H9C-3000CH
300
Rated Load (kg)
1.2
Rated Speed (m/s)
SLAM
Navigation
0.5
Rated Acceleration (m/s²)
Omni-directional
Driving Mode
360° Laser+Auxiliary protection
Obstacle Avoidance
| Dimension L*W*H (mm) | : 2000*1400*480 |
| Transferred Method | : Lifting |
| Weight (kg) | : 900 |
| Angular Accuracy (°) | : ±1 |
| Positioning Accuracy (mm) | : ±10 |
